nor. dia.	out. dia.	D_s	column base & total weight/meter													column flange						c/pipe cover			D_s	F	G	H	J	K	H_R	n₄
			n₁	t_R	n₂	without flange joint					with flange joint					D_C	C_C	O_d	O_d1	n₃	φ	tcv	c/ent	h/ring
			n₁	t_R	n₂	D_B1	C_B1	D_H1	E₁	W₁	D_B2	C_B2	D_H2	E₂	W₂	D_C	C_C	O_d	O_d1	n₃	φ	tcv	c/ent	h/ring
400	406.4	230	8	8	8	720	560	460	140		810	650	550	185		495	465	5.7	425	16	14	12		손잡이	330	16	12	188	12	8	215	6
500	508	330	10		10	840	660	560			940	760	660			610	570	8.4	525	20	19				430	18	15	193	15	10		8
600	609.6	430				960	760	660			1060	860	760			710	670		625						530
700	711.2	530	8	10	12	1120	950	770	190		1230	1050	870	240		815	775		730	24					630	20		195
800	812.8	630				1220	1050	870			1330	1150	970			915	875		830						730
900	914.4	730				1330	1150	970			1450	1270	1090			1030	985		935		23				830
1000	1016	830	7		14	1430	1290	1070			1550	1370	1190			1135	1090		1038	28		15		크렌인	930	23	20	203	20	12		12
1100	1118	900				1540	1400	1180			1660	1480	1300			1235	1190		1138						1020
1200	1220	1000	8		16	1640	1500	1280			1760	1620	1400			1335	1290		1240	32					1120
1300	1320	1100				1740	1600	1380			1860	1720	1500			1435	1390	10	1340						1220
1400	1420	1200		12		1850	1700	1480	200		1980	1830	1610	265		1550	1495		1440		27	20			1320							16
1500	1520	1300	12		18	1950	1800	1580			2080	1930	1710			1650	1595		1540	36					1420	26		206
1600	1620	1400				2070	1900	1700			2200	2050	1830			1750	1695		1640						1520		24	210	24	15
1800	1820	1600				2280	2100	1900			2440	2280	2060			1975	1905		1840		34				1720							20
2000	2020	1700				2480	2300	2100			2640	2480	2260			2175	2105		2040						1900
